Galvanized & Painted Galvanized 10/110 Trapezoidal Plate

Trapezoidally in 10/110 mm section of galvanized and painted galvanized coil sheet
is the formation.

Technical Specifications

Thickness	0.30 - 0.60 mm
Min/Max Width	924 - 1123 mm
Lenght	100 - 12000 mm
Coating Thickness (total of two surfaces)	50 - 350 gr/m2 (iki yüzey toplam)
Steel Type	Steels Suitable for Cold Forming (DX51D+Z, DX52D+Z, DX53D+Z, DX54D+Z, DX56D+Z) Non-Alloy Structural Steels (S220 GD+Z, S250 GD+Z, S280 GD+Z, S320 GD+Z, S350 GD+Z)
Color Option	Can be produced in all RAL codes.
Paint Type	Polyester, Pvdf, Plastisol, PVC
